Air Filter Media

Spray Booth Floor Filters Paint Stop Filters

Product ID： LH-200G , LH-250G , LH-280G , LH-320G
size： 1*20m; 2*20m
Material： Filberglass
Price： USD 0.8-1.2
MOQ： 10Rolls
INQUIRY

Description

Specification of paint stop

　　Filberglass Filter Media/Floor Filter/air filter media/paint stop

　　1. Absorb paint

　　2. Gradual density

　　3. Tensible strength

　　4. High efficiency

　　Filberglass Filters Media(Paint Stop, Floor Filter, Paint Arrestor)

　　Description: It is a high-arrestance filter made of high strength glass fiber with gradual density. Low compressibility keeps its shape and makes fiber purified air effectively. It can absorb the excess particles during paint-spraying operation and reducing pollution to the environment, makes the exhausted air more environmental-friendly and inner circulating air more clean.

　　Application: It's especially suitable for automotive/furniture paint spray booth, coating production line, etc, widely applied to filtration of high quality surface painting with the feature of high arrestance, high efficiency in absorbing extra particle during the course of painting, making air pressure more equally. It is a typical ecological material.

Model	LH-200G	LH-250G	LH-280G	LH-320G
Weight	200g/m2	250g/m2	280 g/ m2	320 g/ m2
Thickness	30mm	50mm	80mm	100mm
Max. Airflow	5400m3/hr	4860m3/hr	4500 m3/hr	3960 m3/hr
Initial Resistance	12pa	12Pa	12Pa	12Pa
Final Resistance	200Pa	200Pa	200Pa	200Pa
Efficiency	74.10%	78.70%	83.30%	89.20%
Nominal Velocity(m/s)	1.45m/sec	1.35m/sec	1.25 m/sec	1.20 m/sec
Dust Holding Capacity	3000g/m2	3560g/m2	4120g/ m2	4780 g/ m2
Max. Working Temp.	150℃	150℃	150℃	150℃
Filtering Grade	G2/EU-2 DIN24185	G3/EU-3 DIN24185	G3/EU-3 DIN24185	G3/EU-3 DIN24185
Flame resistance	F-1 DIN53438	F-1 DIN53438	F-1 DIN53438	F-1 DIN53438
Standard Size	120m; 220m	120m; 220m	120m; 220m	120m; 220m
